Tires and wheels
172
Operation
This is for illustrative purposes only.
Be sure to use the actual load limit for your vehicle stated on the vehicle's tire and load-
ing information label
(e page 171).
The higher the weight of all occupants, the less cargo and luggage load capacity is avail-
able.
Certification label
Even after careful determination of the
combined weight of all occupants, cargo
and the trailer tongue load (if applicable)
as to not exceed the permissible load limit,
you must make sure that your vehicle nev-
er exceeds the Gross Vehicle Weight Rat-
ing (GVWR) and the Gross Axle Weight
Rating (GAWR) for either the front or rear
axle and the Gross Combination Weight
Rating (GCWR) (if applicable).
Under a maximum loaded vehicle condi-
tion, gross axle weight ratings (GAWR's)
for the front and rear axles must not be ex-
ceeded.
Example 1 Example 2 Example 3
Step 1
Combined weight limit
of occupants and cargo
from label
1500 lbs
(700 kg)
1500 lbs
(700 kg)
1500 lbs
(700 kg)
Step 2
Number of occupants
(driver and passengers)
5 3 1
Seating configuration
Front: 2
Rear: 3
Front: 1
Rear: 2
Front: 1
Rear: –
Weight of occupants
Occupant 1:
150 lbs (70 kg)
Occupant 2:
180 lbs (80 kg)
Occupant 3:
160 lbs (75 kg)
Occupant 4:
140 lbs (60 kg)
Occupant 5:
120 lbs (55 kg)
Occupant 1:
200 lbs (90 kg)
Occupant 2:
190 lbs (85 kg)
Occupant 3:
150 lbs (70 kg)
Occupant 1:
150 lbs (70 kg)
Combined weight of all
occupants
750 lbs (340 kg) 540 lbs (245 kg) 150 lbs (70 kg)
Step 3
Available cargo/
luggage and trailer
tongue weight (total
load limit or vehicle ca-
pacity weight from tire
and loading information
label minus combined
weight of all occupants)
1500 lbs –
750 lbs =
750 lbs
(700 kg –
340 kg =
360 kg)
1500 lbs –
540 lbs =
960 lbs
(700 kg –
245 kg =
455 kg)
1500 lbs –
150 lbs =
1350 lbs
(700 kg –
70 kg =
630 kg)
