Features
143
Controls in detail
Cup holders in the front
Example on the right-hand side
1 Cup holder in the storage compartment
in the dashboard
Example on the right-hand side
2 Bottle holder in the front door
Cup holder in the center console
E Pull out cup holder compartment 3 by
recess 4.
Cup holder 5 opens fully.
i Vehicles with the non-smoking package are
equipped with an additional cup holder in place
of the ashtray.
You can change the diameter of the cup
holder.
E Place the container in cup holder 5.
E Press clamping arm 6 onto the con-
tainer.
Cup holders in the rear
E Pull out cup holder 1.
G Warning
Slide the cup holder back underneath the
seat before leaving the vehicle. You could
otherwise be injured by the protruding cup
holder.
