freightliner Sprinter Operator's Manual

Fuses
276
Practical hints
Fuseblock F55/4
Fuse block F55/5
Fuse block F55/6
7 Electronic selector level
module ESM
10 A
8 Terminal 15, tapping
wire body builder, drop
side/3-way tipper
10 A
9 Roof ventilator/siren 15 A
No. Consumer Amp.
10 Terminal 30, tapping
wire body builder
25 A
11 Terminal 15, tapping
wire body builder
15 A
12 D+, tapping wire body
builder
10 A
13 Air conditioning in the
rear
30 A
14 Trailer socket 20 A
15 Trailer recognition de-
vice
25 A
16 Tire pressure monitoring
system (TPMS)/
PARKTRONIC
7.5 A
17 PSM control unit 25 A
18 PSM control unit 25 A
No. Consumer Amp.
19 Overhead control
panel/sliding sunroof
5/25 A
20 Clearance lamps 7.5 A
21 Rear window heating 1 30 A
22 Rear window heating 2 15 A
23 12V socket rear left,
load/passenger
compartment/body
builder electrics
15 A
No. Consumer Amp.
24 12V socket, driver's seat
base
15 A
25 12V socket rear right,
load/passenger com-
partment
15 A
26 Auxiliary heating 25 A
27 Heater booster 25 A
No. Consumer Amp.
28 Exhaust gas aftertreat-
ment – SCR
1
– control
unit
1. Selective Catalytic Reduction (SCR).
10 A
29 Unassigned —
30 Brake booster 30 A
31 Blower unit rear
heating/electric closing
aid (sliding door, left)
30/15 A
32 Exhaust gas aftertreat-
ment – SCR1 – relay
power supply
10 A
33 Electric closing aid (slid-
ing door, left)
15 A
34 Exhaust gas aftertreat-
ment – SCR1 – heater 1
tank
15 A
35 Exhaust gas aftertreat-
ment – SCR1 – heater 2
hose
15 A
36 Exhaust gas aftertreat-
ment – SCR1 – heater 3
delivery pump
10 A
No. Consumer Amp.
