Y Y 0 Y Y Y Y N 5-102
H12 Instantaneous Overcurrent Limiting
(Mode selection)
0: Disable
1: Enable
Y Y 1 Y Y N N N 5-64
5-102
H13 Restart Mode after Momentary
Power Failure (Restart time)
0.1 to 10.0 s Y Y1 Y2 *3 Y Y Y Y N 5-43
5-102
H14 (Frequency fall rate) 0.00: Deceleration time selected by F08,
0.01 to 100.00 Hz/s, 999: Follow the current limit command
Y Y 999 Y Y Y N N
H15 (Continuous running level) 200 to 300 V for 200 V class series
400 to 600 V for 400 V class series
Y Y2 235
470
Y Y Y Y N
H16 (Allowable momentary power
failure time)
0.0 to 30.0 s
999: Automatically determined by inverter
Y Y 999 Y Y Y Y N
H18 Torque Limiter (Mode selection) 0: Disable (Speed control)
2: Enable (Torque current command)
3: Enable (Torque command)
N Y 0 N N Y Y Y 5-103
H26 Thermistor (for motor)
(Mode selection)
0: Disable
1: PTC (The inverter immediately trips with
0h4
displayed.)
2: PTC (The inverter issues output signal THM and
continues to run.)
3: NTC (When connected)
Y Y 0 Y Y Y Y Y 5-104
H27 (Level) 0.00 to 5.00 V Y Y 0.35 Y Y Y Y Y
H28 Droop Control -60.0 to 0.0 Hz Y Y 0.0 Y Y Y Y N 5-105
H30 Communications Link Function
(Mode selection)
Frequency command Run command
0: F01/C30 F02
1: RS-485 (Port 1) F02
2: F01/C30 RS-485 (Port 1)
3: RS-485 (Port 1) RS-485 (Port 1)
4: RS-485 (Port 2) F02
5: RS-485 (Port 2) RS-485 (Port 1)
6: F01/C30 RS-485 (Port 2)
7: RS-485 (Port 1) RS-485 (Port 2)
8: RS-485 (Port 2) RS-485 (Port 2)
Y Y 0 Y Y Y Y Y
H42 Capacitance of DC Link Bus
Capacitor
Indication for replacement of DC link bus capacitor
0000 to FFFF (hex.)
Y N - Y Y Y Y Y 5-107
H43 Cumulative Run Time of Cooling Fan Indication for replacement of cooling fan
(in units of 10 hours)
Y N - Y Y Y Y Y
H44 Startup Counter for Motor 1 Indication of cumulative startup count
0000 to FFFF (hex.)
Y N - Y Y Y Y Y 5-108
H45 Mock Alarm 0: Disable
1: Enable (Once a mock alarm occurs, the data
automatically returns to 0.)
Y N 0 Y Y Y Y Y 5-109
H46 Starting Mode
(Auto search delay time 2)
0.1 to 10.0 s Y Y1 Y2 *7 Y Y Y N Y 5-101
5-109
H47 Initial Capacitance of DC Link Bus
Capacitor
Indication for replacement of DC link bus capacitor
0000 to FFFF (hex.)
Y N - Y Y Y Y Y 5-107
5-109
H48 Cumulative Run Time of Capacitors
on Printed Circuit Boards
Indication for replacement of capacitors
(The cumulative run time can be modified or reset in units
of 10 hours.)
Y N - Y Y Y Y Y
H49 Starting Mode
(Auto search delay time 1)
0.0 to 10.0 s Y Y 0.0 Y Y Y Y Y 5-101
5-109
H50 Non-linear V/f Pattern 1 (Frequency) 0.0: Cancel, 0.1 to 500.0 Hz N Y *8 Y Y N N N 5-36
H51 (Voltage) 0 to 240: Output an AVR-controlled voltage
(for 200 V class series)
0 to 500: Output an AVR-controlled voltage
(for 400 V class series)
N Y2 *8 Y Y N N N 5-109
H52 Non-linear V/f Pattern 2 (Frequency) 0.0: Cancel, 0.1 to 500.0 Hz N Y 0.0 Y Y N N N
H53 (Voltage) 0 to 240: Output an AVR-controlled voltage
(for 200 V class series)
0 to 500: Output an AVR-controlled voltage
(for 400 V class series)
N Y2 0 Y Y N N N
H54 Acceleration Time (Jogging) 0.00 to 6000 s Y Y *2 Y Y Y Y N 5-38
H55 Deceleration Time (Jogging) 0.00 to 6000 s Y Y *2 Y Y Y Y N 5-109
H56 Deceleration Time for Forced Stop 0.00 to 6000 s Y Y *2 Y Y Y Y N
H57 1st S-curve acceleration range
(Leading edge)
0% to 100% Y Y 10 Y Y Y Y N
H58 2nd S-curve acceleration range
(Trailing edge)
0% to 100% Y Y 10 Y Y Y Y N
H59 1st S-curve deceleration range
(Leading edge)
0% to 100% Y Y 10 Y Y Y Y N
H60 2nd S-curve deceleration range
(Trailing edge)
0% to 100% Y Y 10 Y Y Y Y N
*2 6.00 s for inverters with a capacity of 22 kW or below; 20.00 s for those with 30 kW or above
*3 The factory default differs depending upon the inverter's capacity. See Table B.
*7 The motor parameters are automatically set, depending upon the inverter's capacity and shipping destination. See Table C.
*8 The factory default differs depending upon the inverter's capacity. See the table under " Non-linear V/f Patterns 1, 2 and 3 for Voltage" in the description
of F04.
