5-89
The menus available on the standard keypad are described below.
Menu # Menu
LED monitor
shows:
Main functions
0 "Quick Setup"
*fn:
Displays only basic function codes to customize the inverter
operation.
!f__
F codes (Fundamental functions)
!e__
E codes (Extension terminal functions)
!c__
C codes (Control functions)
!p__
P codes (Motor 1 parameters)
!h__
H codes (High performance functions)
!a__
A codes (Motor 2 parameters)
!b__
b codes (Motor 3 parameters)
!r__
r codes (Motor 4 parameters)
!j__
J codes (Application functions 1)
!d__
d codes (Application functions 2)
!u__
U codes (Application functions 3)
!y__
y codes (Link functions)
1 "Data Setting"
!o__
o codes (Optional function)
Selecting each of
these function
codes enables its
data to be
displayed/changed.
2 "Data Checking"
"rep
Displays only function codes that have been changed from
their factory defaults. You can refer to or change those
function code data.
3 "Drive Monitoring"
#ope
Displays the running information required for maintenance or
test running.
4 "I/O Checking"
$i_o
Displays external interface information.
5 "Maintenance Information"
%che
Displays maintenance information including cumulative run
time.
6 "Alarm Information"
&al
Displays the recent four alarm codes. You can refer to the
running information at the time when the alarm occurred.
7 "Data Copying"
'cpy
Allows you to read or write function code data, as well as
verifying it.
For details of each menu item, refer to Chapter 3 "KEYPAD FUNCTIONS."
E54 Frequency Detection 3 (Level) (Refer to E31.)
E55, E56 Current Detection 3 (Level, Timer) (Refer to E34.)
