LD (Low Duty)-mode inverters for light load (5.5 to 75 kW)
Item Specifications
Type (FRN_ _ _G1S-4) 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11 15 18.5 22 30 37 45 55 75
Nominal applied motor
(kW)
*1
(Output rating)
– 7.5 11 15 18.5 22 30 37 45 55 75 90
Rated capacity (kVA)
*2
–
12 17 22 28 33 45 57 69 85 114 134
Rated voltage (V) *3
–
Three-phase 380 to 480 V (with AVR function)
Rated current (A)
–
16.5 23 30.5 37 45 60 75 91 112 150 176
Output ratings
Overload capability
–
120%-1 min
Voltage, frequency
–
380 to 480 V, 50/60 Hz *4
Allowable
voltage/frequency
–
Voltage: +10 to -15% (Interphase voltage unbalance: 2% or less) *5,
Frequency: +5 to -5%
Input power
Required capacity
(with DCR) (kVA)
*6
–
10 15 20 25 30 40 48 58 71 96 114
Torque (%) *7
–
70% 15% 7 to 12%
Braking transistor
–
Built-in –
Built-in braking resistor
Braking time (s)
– 3.7 s 3.4 s –
Braking
Duty cycle (%ED)
– 2.2 1.4 –
DC reactor (DCR) *8 – Option
Applicable safety
standards
– UL508C, C22.2No.14, EN61800-5-1:2003, EN954-1 Cat.3
Enclosure (IEC60529) – IP20, UL open type IP00, UL open type
Cooling method – Fan cooling
Weight / Mass (kg) – 6.5 6.5 5.8 9.5 9.5 10 25 26 31 33 42
(90 to 630 kW)
Item Specifications
Type (FRN_ _ _G1S-4) 90 110 132 160 200 220 280 315 355 400 500 630
Nominal applied motor
(kW)
*1
(Output rating)
110 132 160 200 220 280 355 400 450 500 630 710
Rated capacity (kVA)
*2
160 192 231 287 316 396 495 563 640 731 891 1044
Rated voltage (V) *3 Three-phase 380 to 480 V (with AVR function)
Rated current (A) 210 253 304 377 415 520 650 740 840 960 1170 1370
Output ratings
Overload capability 120%-1 min
Voltage, frequency
380 to 440 V, 50 Hz
380 to 480 V, 60 Hz
Allowable
voltage/frequency
Voltage: +10 to -15% (Interphase voltage unbalance: 2% or less)
*5, Frequency: +5 to -5%
Input power
Required capacity
(with DCR) (kVA)
*6
140 165 199 248 271 347 436 489 547 611 773 871
Torque (%) *7 7 to 12%
Braking transistor –
Built-in braking resistor
Braking time (s)
–
Braking
Duty cycle (%ED) –
DC reactor (DCR) *8 Option
Applicable safety
standards
UL508C, C22.2No.14, EN61800-5-1:2003, EN954-1 Cat.3
Enclosure (IEC60529) IP00, UL open type
Cooling method Fan cooling
Weight / Mass (kg) 62 64 94 98 129 140 245 245 330 330 530 530
*1 Fuji 4-pole standard motor
*2 Rated capacity is calculated assuming the rated output voltage as 220 V for 200 V class series and 440 V for 400 V class series.
*3 Output voltage cannot exceed the power supply voltage.
*4 380 to 440 V, 50 Hz; 380 to 480 V, 60 Hz
*5
3) -61800 (IEC 67 ×
(V) voltageaverage phase-Three
(V) voltageMin. - (V) voltageMax.
(%) unbalance Voltage
=
If this value is 2 to 3%, use an optional AC reactor (ACR).
*6 Required when a DC reactor (DCR) is used.
*7 Average braking torque for the motor running alone. (It varies with the efficiency of the motor.)
*8 A DC reactor (DCR) is optionally provided. Note that inverters with a capacity of 55 kW in LD mode and inverters with 75 kW or above in all modes
require a DCR to be connected. Be sure to connect it to those inverters.
Note: A box () in the above table replaces A or E depending on the shipping destination.
