6.8 17-bit High Resolution ABS Interface Card
6-191
Chap. 6
CONTROL OPTIONS
6.8.3 External dimension drawing
CN4
CN6
CN7(FG)
Frequency
dividing output
signal terminal
（CN5）
Serial PG Wiring Connector (CN3)
Battery
(Option: Is used for
position control.)
Figure 6.8.1 Card Outline Drawing
