6.13 AIO Expansion Card
6-243
Chap. 6
CONTROL OPTIONS
6.13.5 Check function
(1) Optional Module Mounting Check
It is possible to check with the keypad whether the optional AIO expansion card is correctly mounted.
Go to the Program Menu screen from the Operation Mode
screen and select "4. I/O CHECK."
Select the screen with the UP and DOWN keys (
and
)
and check the screen corresponding to the optional AIO
expansion card.
For details, refer to the information provided in this manual on
how to operate the keypad.
As shown in the LCD screen example on the right-hand side,
the corresponding number will be highlighted () if it is
correctly mounted.
(2) I/O check
It is possible to check with the keypad of the inverter the I/O status of optional AIO expansion cards.
Check with Monitor LED
Press the FUNC/DATA key (
) in the operation mode screen
and select the corresponding item.
The 7-segment LED indicator will display the current analog
input status in percentage.
Analog input gain and bias settings can be made by referring to
the LED indicator.
(The LED indicator will not display any analog output status).
Check with LCD screen
Go to the Program Menu screen from the Operation Mode screen and select "4. I/O CHECK."
Select the screen with the UP and DOWN keys (
and
)
and check the screen corresponding to the
optional AIO expansion card.
The screen will display the input voltages of [Ai3] and [Ai4] and the output voltages of [AO4] and
[AO5].
AIO I/O status 1 (Ai3): "0,0" if not connected.
AIO I/O status 1 (Ai4): "0,0" if not connected.
AIO I/O status 1 (Ao4)
AIO I/O status 1 (Ao5)
Ａｉ３＝±××．×Ｖ
Ａｉ４＝ ××．×Ｖ
ＡＯ４＝±××．×Ｖ
ＡＯ５＝±××．×Ｖ
∧∨ÆＰＡＧＥ ＳＨＩＦＴ１４
ＯＰ―Ａ：ＶＧ１－ＡＩＯ
ＯＰ－Ｂ：
ＯＰ－Ｃ：
∧∨ÆＰＡＧＥ ＳＨＩＦＴ ９
＜ＬＥＤ ＭＮＴＲ＞ １８
Ａｉ ＡＤＪＵＳＴＭＥＮＴ
（Ａｉ３）
Ｆ／ＤÆＬＥＤ ＳＨＩＦＴ
