218 Upgrade and Maintenance Manual TX100 S3 Core Edition
Cabling
15.1 Cabling overview
No. Name Cable number Routing
1
On/Off switch
and HDD access
LED cable
T26139-Y4001-
V211
from On/Off button and HDD
access LED to system board
2
SATA power
5HDD cable
T26139-Y4012-
V101
from all drives to system board
3
Front USB cable
T26139-V4018-
V2
from front USB to system board
4
SATA data ODD
cable
T26139-Y4028-
V101
from optical disk drive to system
board
5
SATA data HDD
3.5-inch cable
(red)
T26139-Y4028-
V152
from HDD 1/2 to system board
6 SATA data HDD
3.5-inch cable
(grey)
T26139-Y3958-
V107 from HDD 3/4 to system board
7
4x SATA
connectors to
MiniSAS (RAID
controller) cable
T26139-Y3964-
V111
from all drives to RAID controller
8 SATA data ODD T26139-Y4028-
V101
from ODD to system board
9
BBU cable
(I
2
C bus)
T26139-Y3987-
V2
from BBU to RAID controller
10
Power adapter
SATA to 2x PATA
(4pins)
T26139-Y3942-
V1
from power cable to backup
drive
11
USB accessible
drive cable
T26139-Y3973-
V2
from USB backup drive to
system board
12
SATA data ODD
(long version)
T26139-Y3958-
V205
instead of T26139-Y4028-V101
Table 6: List of used cables
