Fujitsu PRIMERGY TX100 S3 Core Edition Upgrade And Maintenance Manual

TX100 S3 Core Edition Upgrade and Maintenance Manual 235
Appendix
16.1.3 Server interior
Figure 155: PRIMERGY TX100 S3 Core Edition interior
Pos. Component
1 Expansion card slots
2 Processor / CPU heat sink / CPU fan
3 HDD 2
4 TPM board (not applicable for TX100 S3 Core Edition)
5 CMOS battery (not visible, located under system fan 2)
6 HDD 1
7 System fan 1 (fan 3 on the SEL)
8 BBU (if installed)
9 HDD 3
10 HDD 4
:;
<
=
/ 0
9
5
6
7
8
3 421

Fujitsu PRIMERGY TX100 S3 Core Edition Specifications

General

Brand	Fujitsu
Model	PRIMERGY TX100 S3 Core Edition
Category	Server
Language	English
