TX100 S3 Core Edition Upgrade and Maintenance Manual 51
Basic hardware procedures
4.4.1 Installing the front cover
Figure 11: Installing the front cover
Ê Hook the three tabs on the front bezel into the notches in the chassis (1).
Ê Carefully close the front bezel (2). Make sure that all three locking latches
properly engage (3).
/
/
/
