24 Upgrade and Maintenance Manual TX100 S3 Core Edition
Before you start
2.3 Tools you need at hand
When preparing the maintenance task, ensure that all required tools are
available according to the overview below. You will find a list of required tools at
the beginning of each procedure.
Screw driver /
Bit insert
Screw Usage Type
Phillips
PH2 / (+) No. 2
hexagonal cross
SW5 / PZ2
System
board, slot
bracket,
chassis
M3 x 4.5 mm
(silver)
C26192-Y10-C67
Phillips
PH2 / (+) No. 2
hexagonal cross
SW5
System fans
M5.0 x 16 mm
(silver)
C26361-K1015-
C98
Table 2: List of required tools and used screws
