224 Upgrade and Maintenance Manual TX100 S3 Core Edition
Cabling
15.2 Replacing the power cable
Figure 146: Power cable T26139-Y4012-V101
15.2.1 Required tools
● Preliminary and concluding steps: tool-less
● Replacing the power cable: tool-less
15.2.2 Preliminary steps
Before replacing the power cable, perform the following steps:
Ê Shut down the server as described in section "Shutting down the server" on
page 40.
Ê Remove the AC power cord from the cable tie and disconnect it from the
system as described in section "Disconnecting the power cord" on page 41.
Ê Open the side cover as described in section "Removing the side cover" on
page 43.
Field Replaceable Units (FRU)
Average task duration: 10 minutes
