TX100 S3 Core Edition Upgrade and Maintenance Manual 145
Processo
r
11.2.8 Concluding steps
Perform the following procedures to complete the task:
Ê Close the side cover as described in section "Installing the side cover" on
page 56.
Ê Reconnect the AC power cord to the power supply unit and secure it with a
cable tie as described in section "Connecting the server to the mains" on
page 57.
Ê If available, update the system board BIOS to the latest version as described
in section "Updating the system board BIOS via USB stick" on page 67.
11.3 Replacing the processor heat sink
11.3.1 Required tools
● Preliminary and concluding steps: tool-less
● Removing and installing the processor heat sink:
– Phillips PH2 / (+) No. 2 screw driver
Field Replaceable Units (FRU)
Average task duration: 15 minutes
