Fujitsu PRIMERGY TX100 S3 Core Edition Upgrade And Maintenance Manual

TX100 S3 Core Edition Upgrade and Maintenance Manual 97
Hard disk drives
7.4 Replacing a 3.5-inch HDD
V CAUTION!
All HDDs must be uniquely identified so that they can be reinstalled in
their original mounting locations later. If this is not done, existing data can
be lost.
7.4.1 Required tools
● Preliminary and concluding steps: tool-less
● Replacing a 3.5-inch HDD: tool-less
7.4.2 Preliminary steps
Before replacing a 3.5-inch HDD, perform the following steps:
Ê Shut down the server as described in section "Shutting down the server" on
page 40.
Ê Remove the AC power cord from the cable tie and disconnect it from the
system as described in section "Disconnecting the power cord" on page 41.
Ê Open the side cover as described in section "Removing the side cover" on
page 43.
Only applicable for removing intact HDDs:
Ê Before removing a non-defective HDD, put the drive into "Offline" mode
using your RAID configuration software.
I For further information, please refer to the "ServerView Suite RAID
Management" user guide, available online at http://manuals.ts.fujitsu.com
or from the ServerView Suite DVD 2 supplied with your PRIMERGY
server.
Customer Replaceable Units (CRU)
Average task duration: 5 minutes
