TX100 S3 Core Edition Upgrade and Maintenance Manual 47
Basic hardware procedures
4.3.2.2 Removing the backup drive
Figure 8: Disconnecting cables from the backup drive
Ê Disconnect all cables from the backup drive.
1 Power adapter cable
2 USB cable
/
