46 Upgrade and Maintenance Manual TX100 S3 Core Edition
Basic hardware procedures
Figure 7: Removing the optical disk drive
Ê Press the locking latch in the direction of the arrow (1) and push out the
accessible drive from behind (2).
Ê Remove the accessible drive from its bay.
/
