TX100 S3 Core Edition Upgrade and Maintenance Manual 223
Cabling
Fan cabling
Figure 145: Fan cabling
PWR
FAN1 SYS
USB
DAT
HDD
ACTIVITY
Front panel
SATA
PWR
PC2009
TPM
SATA6
SATA5
USB FRONT
FAN
CPU
FAN2
SYS
SATA2
SATA1
SATA4
SATA3
CPU fan
HDD fan
Front fan
