Fujitsu PRIMERGY TX100 S3 Core Edition Upgrade And Maintenance Manual

238 Upgrade and Maintenance Manual TX100 S3 Core Edition
Appendix
No. Print Description
1 POWER Power supply connector
2 POWER SATA Power supply connector
3 PC2009 Power supply connector
4 Front panel Front panel
5 FAN CPU Connector for CPU fan
6TPM
Connector for TPM
(not applicable for TX100 S3 Core Edition)
7 HDD ACTIVITY Connector for HDD activity LED
8 FAN2 SYS Connector for system fan 2
9 SATA 1-6 SATA 1-6 connector
10 USB DAT USB connector (only for internal USB devices)
11 USB FRONT Connector for USB on the front side
12 FAN1 SYS Connector for system fan 1

Fujitsu PRIMERGY TX100 S3 Core Edition Specifications

General

Brand	Fujitsu
Model	PRIMERGY TX100 S3 Core Edition
Category	Server
Language	English
