Figure 5-31: Manual Sequencer Fields
5.14.6 Manual Sequencer # 1 - 8
Each of the eight manual sequencer boxes includes the following options:
• Run and Loop Enable Checkboxes - When the Manual Sequencer Request checkbox is
checked, the user can run individual manual sequences by checking the Run checkbox for
any particular manual sequence. The Loop Enable checkbox can also be checked to allow
the manual sequence to run indefinitely.
The Run and Loop Checkboxes can be ignored if a digital input is used to
run a manual sequence because the sequence would run continuously
until the digital input was put in an open state.
• Digital Input Checkbox - The Digital Input checkbox should be checked to enable the
dedicated digital contact for that manual sequencer to initiate.
