Revision 1 117 9/10/2019
5.19 Maintenance Tab
The Maintenance tab (Figure 5-41) allows the operator to calibrate the six analog outputs and
test the operation of any of the relays or solenoids under direct board control. This feature is
useful during analyzer commissioning.
Figure 5-41: Maintenance Tab
Changing Parameters in the Maintenance tab may affect operation of the
unit. It is recommended that any change in this page be done by authorised
personnel only.
