Section 7 Maintenance
7.1 Overview
The analyzer is designed for automatic trouble-free operation under the continuous
supervision of the internal computer. As described in Sections 4 and 5, a series of alarms are
presented on the hand held keypad and the GUI if an operation or function is not performing
in the appropriate manner to alert the user that a problem exists. A detailed discussion of
service protocols is presented in Section 8.
Routine Preventative Maintenance of the analyzer consists of a periodic performance of the
Maintenance Check-out Procedure (Section 7.2). Routine maintenance will correspond to
tape usage, which is 4 - 6 weeks for most applications.
On a periodic basis, it will be necessary to replace certain components of the system such as
the sensing tape and the filter element. Replacement procedures for these items are
described in Section 7.3-7.6.
7.2. Routine Maintenance Procedures
a) Check display for any alarms (press F2 on keypad). See Section 8 for information about
resolving any active alarms
b) Disable alarms by pressing the BYPASS button.
c) Turn off gas to the analyzer. Pull back the Compression Head and inspect the Sample
Chamber for paper dust and dirt. If required remove the Sample chamber assembly and
clean (see Section 7.3).
d) Change tape and ensure the tape is re-inserted properly (see. Section 7.3).
e) Advance tape with TAPE ADV key.
f) Check for proper take-up.
g) Top up the level of the water solution to the red line (see Section 7.7).
h) Re-calibrate the sensor. Press F4 (MNT) on the keypad, then press F1. Press F4 to scroll
down the screens to SenCal. Press the EDIT key and press the ENTER key to toggle the
parameter to ON. The sensor will calibrate and then automatically go online.
i) Check the mV reading is 0 mV +/- 10 mV at the start of the cycle.
j) Reset the tape length to 300 ft through the keypad. (F4, F1, press the EDIT key then
enter the value of 300 and press the ENTER key)
k) Check the sample system as described in Sections 7.4 and 7.5
