4.7 The Display Menu
When F3 is pressed on the main page, the Display menu appears as shown in Figure
4-6.The function keys lead to four menus that are described in Sections 4.7.1 through 4.7.4
mV Run State Time
6 1S1 S1 115
10.0 ppm
F1 F2 F3 F4
SQNC IO READ SCHED
Figure 4-6: Display Menu
4.7.1 The SQNC Menu
A typical SQNC (Sequence) menu is presented in Figure 4-7. The sequence is entered via
the GUI (Section 5.14) and indicates the order of measurements that occur during a cycle.
The sequence cannot be edited via the hand held keypad.
mV Run State Time
6 1S1 S1 115
• AUTO
• S1: SAMPLE
• S1: REF1
F1 F4
PGUP PGDN
Figure 4-7: SQNC Menu
When F4 (PGDN) is pressed, additional lines in the sequence will be displayed.
4.7.2 IO Menu
A typical IO (Input/Output) menu is presented in Figure 4-8. The values that are presented
are the live values for the analog (AO) outputs, digital (DO) outputs and relays that have been
activated via the GUI and cannot be edited via the hand held controller
