5.2.2.3 General Toolbar
The General toolbar contains several buttons that allow the user to load and save
configuration files, print configurations, and open the context selective help file. Table 5-3
shows the buttons in the General Toolbar. A saved configuration file can be opened, edited
and re-saved when offline (not connected to the analyzer).
Table 5-3: General Toolbar Buttons
Button
Name
Function
Open
Opens a saved analyzer configuration file. This can be
done online or offline.
Save Current
Configuration
Saves current configuration to a file. If the configuration
has been saved to a file previously, pressing this button
will overwrite the existing configuration file. If offline, a
saved configuration file needs to be opened before one
can be saved.
Save
Configuration to
a new file
Saves current configuration to a new file with a file
name of the user’s choosing. If offline, a saved
configuration file needs to be opened before one can
be saved.
Exit
Pressing this button will cause the GUI to close. It is
advisable to log off the analyzer prior to exiting the GUI.
5.2.3 Application Screens (Tabs)
The GUI is a Tab driven system which includes 17 tabs listed in Table 5-4. Each tab contains
information about the analyzer and most allow for editing of system parameters (in Update
mode). The specifics of each tab will be discussed in Section 5.4 to 5.20.
