Revision 1 31 9/10/2019
3.4 Installation of the Software
3.4.1 Computer Requirements
Table 3-1 shows the computer requirements for the application software.
Table 3-1: Computer Requirements for Application Software
Microsoft
®
Windows™ 2000, XP, Vista or Windows 7
Disk Drives
A CD ROM drive is required to read the installation disk, and a
minimum of 20 mB of space is required for installation on the
PC hard drive. Additional space is required to save analyzer
configurations and archive data.
Serial/USB Port
The analyzer can be connected to the PC via either a 9-pin
male serial connector or via a standard USB cable (included
with the analyzer). The COM port used to connect to the
system cannot be used for any other purposes; otherwise
connecting to the system will not be possible.
Minimum required resolution is 1024 x 768.
3.4.2 Install the Application Software
The application program that is included with the analyzer allows the operator to perform
analyses and configure all aspects of the analyzer’s operation. The application program is
capable of communicating with the analyzer through USB, RS-232 (serial), or High Speed
LAN (Arcnet) and allows the user to set up MODBUS communications.
To install the application software:
a) Insert the compact disk that was included with the system into the CD ROM drive of the
personal computer. A window will be presented showing the contents of the CD (Figure
3-3).
Figure 3-3: CD Contents
