Galvanic Applied Sciences ProTech903W - Analyzer Reading Menu; Analyzer Schedule Menu

Revision 1 55 9/10/2019
mV Run State Time
6 1S1 S1 115
Analyzer IO State:
AO_1 mA 4.06
AO_2 mA 4.09
AO_3 mA 4.11
F1 F2 F3 F4
PGUP PGDN
Figure 4-8: The IO Menu
4.7.3 Analyzer Reading Menu
A typical Analyzer Reading menu is presented in Figure 4-9. The values that are presented
are the most recent value for the various reading for each analysis (e.g. S1:SAMPLE 10.0
means that the last reading for phosgene was 10 ppm) and cannot be edited.
mV Run State
Time
6 1S1 S1 115
Analyzer Reading:
S1: SAMPLE 10.0
S1:REF1 6.7
S1:REF2 8.9
F1 F2 F3 F4
PGUP PGDN
Figure 4-9: Analyzer Reading Menu
4.7.4 Analyzer Schedule Menu
The Analyzer Schedule menu (Figure 4-10) shows what stream is currently being analyzed
and what streams (if any) are pending.
mV Run State Time
6 1S1 S1 115
Analyzer Schedule:
S1:SAMPLE ON
S1:REF1 PENDING
F1 F2 F3 F4
PGUP PGDN
Figure 4-10: Analyzer Scheduler Menu
