Garmin G3X - Page 273

190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 21-2
Custom
Temperature
50-150C Thermistor (e.g.
VDO 320-XXX series)
N/A
RTD (e.g. UMA 1B3XR
series)
N/A
UMA temperature sensors without
the "R" designation are not
compatible
Rotax 965531 (thermistor) N/A
Rotax 966385 (thermistor) N/A
Type J thermocouple N/A
Type K thermocouple N/A
MS28034 (MIL-T-7990
RTD)
N/A
Cylinder Head
Temperature
(CHT)
50-150C Thermistor (e.g.
VDO 320-XXX series)
N/A
Type J Thermocouple N/A
Type K Thermocouple
(Alcor 86253)
494-70000-00
Type K Thermocouple
(other)
N/A
Rotax 965531 N/A
Rotax 966385 N/A
Discrete Inputs
Active High or Low:
Canopy Warning, Gear
Down Reminder, etc.
N/A
Engine Torque
Garmin GPT 150G 011-05783-30
Uses custom user-defined
calibration (0-150 psiG pressure
to torque)
Kavlico P4055-5020-4 N/A
Uses custom user-defined
calibration (0-150 psiG pressure
to torque)
Any voltage-output torque
transducer
N/A
Uses custom user-defined
calibration (voltage to torque)
Exhaust Gas
Temperature
(EGT)
Type K thermocouple
(Alcor 86255)
494-70001-00
Type K thermocouple
(other)
N/A
Table 21-1 Compatible Engine/Airframe Input Sensors
SENSOR TYPE
COMPATIBLE
SENSORS
GARMIN PART
NUMBER*
NOTES
*Items with a Garmin part number may be included in a G3X Sensor Kit (Section 21.2), and are available
individually from Garmin Dealers
