190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 21-3
Fuel Flow
(two sensors
required for
differential fuel
flow)
EI FT-60 494-10001-00 0-70 gal/hr
EI FT-90 N/A 0-125 gal/hr
EI FT-180 N/A 0-250 gal/hr
Floscan Series 200 N/A 0-60 gal/hr
Floscan 231 N/A 0-90 gal/hr
Any frequency-output fuel
flow transducer
N/A
Uses custom user-defined
calibration (0-5 kHz frequency to
fuel flow)
Fuel Pressure
Garmin GPT 15G 011-05783-10 0-15 psiG
Kavlico P4055-5020-2 011-04202-10 0-15 psiG
Garmin GPT 75G 011-05783-20 0-75 psiG
Kavlico P4055-5020-3 N/A 0-75 psiG
Kavlico P4055-75G N/A 0-75 psiG
UMA EU07D N/A 0-7 psi differential
UMA 1EU35G N/A 0-35 psiG
UMA 1EU70D N/A 0-70 psi differential
UMA 1EU70G N/A 0-70 psiG
UMA 1EM2K N/A 0-2500 psiG
Any voltage-output
pressure sensor
N/A
Uses custom user-defined
calibration (voltage to pressure)
Fuel Quantity
Any capacitive fuel quantity
sensor (requires external
conversion to voltage or
frequency)
N/A
Uses custom user-defined
calibration (voltage or frequency
to fuel quantity)
Any resistive fuel quantity
sensor
N/A
Uses custom user-defined
calibration (voltage to fuel
quantity)
Any voltage-output fuel
quantity sensor
N/A
Uses custom user-defined
calibration (voltage to fuel
quantity)
Any frequency-output fuel
quantity sensor
N/A
Uses custom user-defined
calibration (frequency to fuel
quantity)
Table 21-1 Compatible Engine/Airframe Input Sensors
SENSOR TYPE
COMPATIBLE
SENSORS
GARMIN PART
NUMBER*
NOTES
*Items with a Garmin part number may be included in a G3X Sensor Kit (Section 21.2), and are available
individually from Garmin Dealers
