Garmin G3X User Manual

190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 30-43
6. Three required calibration points (Minimum Visible AOA Calibration, Caution Alert AOA
Calibration, Stall Warning AOA Calibration) are captured during the calibration procedure, in
addition to one optional calibration (Approach Target AOA Calibration, if desired) point. It is
recommended to capture each calibration point in the following sequence. Attempting to calibrate
them out of order may result in a failed calibration.
Recommended Order of Calibration:
1. Minimum Visible AOA Calibration (Required)
2. Caution Alert AOA Calibration (Required)
3. Stall Warning AOA Calibration (Required)
4. Approach Target AOA Calibration (Optional)

Garmin G3X Specifications

General

Display Type	LCD
Touchscreen	Yes
Power Input	10-32 VDC
Connectivity	Bluetooth, Wi-Fi (optional)
Interfaces	RS-232
GPS	Internal GPS/WAAS receiver
AHRS	Integrated AHRS
Air Data Computer	Integrated Air Data Computer
Autopilot Compatibility	Compatible with Garmin autopilots
Operating Temperature	-20°C to +55°C
Sunlight Readability	Sunlight readable display
Screen Size	10.6 inches
