190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 30-102
Figure 30-34 General Autopilot Configuration Page
Flight Control System
Monitors
Enables flight control system monitoring against the internal AHRS of a
GMC 507 Autopilot controller. This is an additional set of monitors that
have the ability to disconnect the autopilot based upon a range of defined
flight parameters. If this setting is enabled, the installer will need to enter
a value for yaw offset of the GMC 507 LRU, as well as perform a pitch/roll
offset calibration as outlined in Section 30.4.7.2.1
Table 30-8 General Tab, Autopilot Configuration Settings
Configuration Setting Description
