190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page 30-155
MapMX - Receives flight plan and navigation data from a Garmin IFR GPS navigator, and optionally
outputs frequency tuning data and receives radio status data for on-screen radio display. The preferred data
source when interfacing with an external navigator, and is only available from Garmin units with a WAAS
GPS receiver. When MapMX data is received, the G3X display can show more accurate information about
the external navigator flight plan (e.g. DME, arcs, and holding patterns).
GTX TIS-A In - Receives TIS A-data from a Garmin Mode-S panel-mount transponder. If the
transponder is connected to the ADAHRS 1 LRU (as shown in Section 24.2
or Appendix G.2), it is not
necessary to connect its output to a GDU RS-232 port.
TIS-A In/NMEA & VHF Out - Receives TIS-A data and transmits out both NMEA data, at 9600 baud,
and VHF frequency tuning information to a Garmin Nav/Comm radio. Note that if a transponder is
connected to the ADAHRS 1 LRU (as shown in Section 24.2
or Appendix G.2), it is not necessary to select
TIS-A In, as the transponder data is received through the ADAHRS 1 LRU.
Integrated Autopilot – For use with Autopilots that use both ARINC 429 and bi-directional RS-232 data
(ARINC 429 output set to Autopilot). Integrated Autopilot is a proprietary serial format that provides
autopilot control softkeys and status annunciations on the G3X PFD. See wiring examples in Section 24.2
and Appendix G.2
.
Note the following when configuring the communication settings:
· Each GNS™ 4XX/5XX receiver, GNS 480, or GTN 6XX/7XX series unit must be connected to a
MapMX/Aviation RS-232 input on one of the GDU 4XX units (in addition to the ARINC 429
connection(s)). ARINC 429 data input from a GNS 4XX/5XX, GNS 480, or GTN 6XX/7XX
series unit will be ignored unless a corresponding MapMX/Aviation RS-232 input is also
configured.
· When connecting two GNS 4XX/5XX, GNS 480, or GTN 6XX/7XX series units to the G3X
system, connect the MapMX/Aviation RS-232 output from NAV 1 to an RS-232 input on PFD1,
and connect the MapMX/Aviation RS-232 output from NAV 2 either to an RS-232 input on the
MFD, or to a higher-numbered RS-232 input on PFD1.
· Highlight the ‘GPS1’, ‘GPS2’, etc. fields on the Main Configuration page to verify which RS-232
and ARINC 429 inputs the G3X system is currently using for NAV 1 and NAV 2.
Vertical Power – A 3rd party LRU that integrates with the G3X to monitor and control the entire electrical
system through the GDU.
CO Detector - Receives data from a third-party carbon monoxide detector. Refer to the G3X Touch Pilot’s
Guide for further information.
Lightning Detector - Receives lightning strike data and transmits heading data to a third-party lightning
detector.
NOTE
Some panel-mount GPS navigators and NAV/COM radios do not transmit RS-232 data
when they are in configuration mode. To verify RS-232 connections, make sure these units
are operating in normal mode.
