f) Adjust the servo gain so the aircraft properly responds to the pitch guidance from the flight
director
i. Overpower the autopilot to fly away from the current flight director commanded pitch
ii. Release controls and monitor autopilot response and closure back to commanded pitch
iii. Set the SERVO GAIN higher to make the autopilot more aggressive
iv. Set the SERVO GAIN lower to make the autopilot less aggressive
2. The pitch servo has additional expert settings that can be adjusted to achieve the desired vertical
mode performance. These settings are detailed in Appendix H.4.5.9
and should only be adjusted
after studying the description to properly understand their effect on the pitch servo. See preceding
note
to access the expert settings.
