190-01115-01 G3X™/G3X Touch™ Avionics Installation Manual
Rev. AV Page H-64
2.Left foot rudder to swing ball back right
3.Engage YD by pressing the YD button on the GMC Mode Controller as ball
swings through the center
4.Set SERVO GAIN so the established yaw body rate from the yaw doublet is
properly dampened out
a.Set the SERVO GAIN higher to make the yaw damper more aggressive
b.Set the SERVO GAIN lower to make the yaw damper less aggressive
2. The yaw servo has additional advanced and expert settings that can be adjusted to achieve the
desired yaw damping performance. These settings are detailed in Appendix H.4.5.9
and should
only be adjusted after studying the description to properly understand their effect on the yaw
servo. See preceding note
to access the advanced/expert settings.
