Setup Procedures: MSpO2 Setup Screen
MSpO2 Setup Screen
Select the MSPO2 softkey to display the MSpO2 Setup screen (Figure 5-4). For
settings information, refer to Appendix A, “Factory Defaults” .
Figure 5-4. Nellcor MSpO
2 Setup Screen
NOTE: If you are using Masimo (instead of Nellcor) technology, the Response
Time setting will be missing on your Setup Screen. In its place, a setting
for Averaging Time and Sensitivity will display.
Response Time (Nellcor Module Only)
Choose a response time modes in order to compensate for different levels of patient
activity.
Slow: Uses a 10- to 15-second averaging period and is least affected by patient
movement. When this setting is selected, dashes “– – –” replace the pulse value
displayed in the MHR/P area.
Normal: Uses a 5- to 7-second averaging period and is recommended in cases
where the patient is relatively inactive.
Fast: Uses a 2- to 3-second averaging period and is most affected by patient
movement.
Sensitivity (Masimo Module Only)
This menu option appears only when using a Masimo module and sensor.
Normal: Use the Normal sensitivity setting for normal patient monitoring
purposes.
Maximum: Use the Maximum sensitivity setting for improved low perfusion
performance and for faster tracking of rapid MSp02 saturation changes.
165
172
30
97%
MSpO2
EXIT
US
FECG
TOCO
ALARM HIGH LOW
MSpO
2: 100 95 %
MHR/P: 120 50 BPM
AUDIO ALARMS: ON VOLUME: 5
RESPONSE TIME: NORMAL
PRINT INTERVAL: 5 MIN
% O2 TRACE: OFF
MSpO
2 SETUP
To Next Page
