3-10 120 Series Maternal/Fetal Monitor Revision B
2015590-001
Controls, Indicators, and Connectors: Front Panel Displays
Additional Parameters
The additional parameters area displays NBP, MHR/P, and MSpO2 data.
Maternal NBP
The maternal NBP section is summarized by Figure 3-6 and Table 3-6.
Figure 3-6. NBP Display
Table 3-6. NBP Display
Name Description
A NBP Time Stamp
The time (in 24-hour format) of the last blood
pressure measurement.
B NBP Values
The systolic/diastolic and mean arterial pressures
(MAP) are each indicated by up to three digits—
representing mmHg.
During a determination, the instantaneous cuff
pressure displays in place of the mean arterial
pressure and is denoted by the title
CUFF.
C
NBP Alarm Setting
Indicator
This symbol provides information about the NBP
audio alarm and the NBP high/low alarm limit
settings.
îš„ : An alarm setting is turned off.
îš„ : All alarm settings are enabled.
D NBP Mode Title
Select the mode title to access the NBP Setup
screen.
E NBP Countdown Timer
The clock symbol represents activation of the auto
mode. The countdown timer indicates the minutes
and seconds until the next automatic reading.
130/ 85
NBP
MAP (107)
03:15
11:41
D
E
C
B
A
