Revision B 120 Series Maternal/Fetal Monitor 9-21
2015590-001
General Maintenance: Maternal Blood Pressure Tests
Patient-to-Line Leakage for FSpO2
1. Connect an FSpO2 test body to the monitor’s front panel FSpO2 input. Use the
assembly leakage cable for the test body.
2. Set the fixture’s
Leakage switch to Line.
3. Turn ON the monitor using the monitor’s power switch.
4. Verify the following:
F < 50 µA (100, 120, 220, 230, or 240 VAC monitors)
5. Record the patient-to-ground leakage for the following conditions:
Table 9-10. Patient-to-Line Leakage Conditions for FspO
2
Neutral Ground Power (Polarity)
Closed Closed Normal
Closed Closed Reversed
Open Closed Normal
Open Closed Reversed
