Revision B 120 Series Maternal/Fetal Monitor 11-1
2015590-001
Chapter 11
Peripheral Devices 11
The 120 Series Monitor allows connection to optional peripheral equipment.
Some of the connectors are standard on each monitor while others are part of an optional
communications package. All connectors are described in this section.
NOTE: Refer to “Chapter 12, Upgrading a 120 Series Monitor”, for more information.
This section discusses the following:
Standard Input/Output Connectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-2
Nellcor Puritan Bennett Model N-200 Maternal Pulse Oximeter 11-5
Nellcor Puritan Bennett Model N-400 Fetal Pulse Oximeter . . . . . . . . . . . . . . . . . . . . 11-6
DINAMAP Models 1846, 1846SX, and 1846SX/Oxytrack, 8100, and 8100T11-7
Quantitative Sentinel/Perinatal System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-8
Model 115-Compatible Communications Protocols . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-9
Optional Communication Package . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11-18
