Revision B 120 Series Maternal/Fetal Monitor 3-5
2015590-001
Controls, Indicators, and Connectors: Front Panel Displays
Front Panel Displays
The monitor’s display is divided into five horizontal sections. The content and
layout of the display can change, depending on which functions are installed in the
monitor and the modes of operation in use.
Display Example
Figure 3-2, “Model 129 Display Example,” on page 3-6, provides an example of a
Model 129 display. In this example:
Blood pressure is not active as indicated by the absence of numerics.
Maternal pulse oximetry is active.
MECG is selected as the heart rates source as indicated by the MECG mode title
softkey—rather than
PULSE.
The MECG waveform is displayed at 25 mm/sec, at a size of 2X, with lead II
selected.
Heartbeat coincidence is enabled as indicated by the HBC acronym in the
primary labor parameters area.
All alarms are enabled as indicated by .
Table 3-2. Display Summary
Display Section Item Mode
Primary Labor Parameters
Fetal Heart Rate 1 (FHR1) US, US2, FECG, or INOP
Fetal Heart Rate 2 (FHR2) US, US2, or INOP
Uterine Activity (UA) TOCO, IUP, or INOP
Additional Parameters
Maternal Blood Pressure NBP
Maternal Heart/Pulse Rate MECG or PULSE
Fetal or Maternal SpO
2 %FSpO2 or %MSpO2
Waveform
Fetal ECG Waveform; Maternal ECG Waveform; Fetal
SpO2 Pulsatile Waveform; or Maternal SpO2 Pulsatile
Waveform
FECG, MECG, FSpO2, MSpO2, or
OFF
Time
Current Time; [LABEL] FROZEN Message, and Time of
Activation
Softkeys System Configuration Softkey Controls
