11-2 120 Series Maternal/Fetal Monitor Revision B
2015590-001
Peripheral Devices: Standard Input/Output Connectors
Standard Input/Output Connectors
Remote Marks Connector
This receptacle is provided for connection to a Corometrics Model 146 Fetal
Acoustic Stimulator.
Remote Marks Connector
This receptacle is provided for connection to an optional Corometrics Remote Event
Marker. A Corometrics Remote Event Marker is used to annotate the strip chart
recorder paper with a mark.
The printed mark can be configured as , commonly used to record an “event”; or it
can be configured as , commonly used as an indication that the mother has
perceived fetal movement. The monitor is factory set with the mark configured as an
arrow. Refer to “Install Options Screen” on page 5-26 for more information on
selecting the mark. Refer to the instructions accompanying the Remote Event
Marker for more information about using the accessory.
ECG Out Connector
This 3-conductor stereo phone jack permits recording of FECG or MECG trends on
an external recorder. FECG signals are output at +80 dB with a bandwidth of 1.0 to
100 Hz. MECG signals are output at +60 dB with a bandwidth of 0.5 to 40 Hz. The
output level from this port is 10 V/mV for FECG and 1 V/mV for MECG.
CAUTION
JACK SIZES—Service personnel who are familiar with other
Corometrics monitors should be aware that the stereo phone jack
used on the 120 Series Monitor is a different size than that used on
previous monitors.
J108 Connector (Corolan Interface)
The Corolan connector is a 25-pin connector for interfacing to a Corometrics
Monarch 8000 Obstetrical Management and Archival System or a Quantitative
Sentinel/Perinatal System using Corolan cabling.
For detailed information about connecting to a Monarch 8000 System, refer to the
“Systems Pre-Installation Manual” (P/N 1279AA). For detailed information on
connecting to a Quantitative Sentinel/Perinatal System, refer to the “Quantitative
Sentinel Networking Pre-Installation Manual” (P/N 13417AA).
