5-18 120 Series Maternal/Fetal Monitor Revision B
2015590-001
Setup Procedures: Master Alarm Setup Screen
Master Alarm Setup Screen
Select the ALARMS softkey to display the Master Alarm Setup screen (Figure 5-8).
Each of the fields on this screen can be accessed under the individual parameter
setup screens. For available settings, refer to Appendix A, “Factory Defaults” .
Figure 5-8. Master Maternal Alarm Setup Screen
Audio Alarms
Individual fields enable/disable the audio alarm functions for NBP, MSpO2, and
MECG. The settings are summarized as follows:
Off: Only a visual indication is provided for an alarm.
On: Both visual and audible (if enabled) indications are provided for an alarm
condition.
Re-Alarm
When an audio alarm is cancelled using the Alarm Silence pushbutton, the audible
indication is removed. However, for MECG and MSpO
2 monitoring and during a
paper-load–error condition, an alarm will be re-issued if the alarm state continues
after a specified amount of time. This field adjusts the temporary silence period.
Alarm Limits
These fields adjust the high and low alarm limits for NBP, MHR/P, and MSpO2.
Volume
This field controls the volume of all alarms.
165
172
+1
30
EXIT
US
FECG
TOCO
MASTER ALARM SETUP
ALARM HIGH LOW
SYSTOLIC: 160 90 MMHG
DIASTOLIC: 90 50 MMHG
MAP: 140 50 MMHG
MHR/P: 120 50 BPM
MSpO
2: 100 95 %
VOLUME: 5
AUDIO ALARMS
NBP: ON MHR/P: ON MSpO
2: ON
RE-ALARM: 120 SEC
To Next Page
