Revision B 120 Series Maternal/Fetal Monitor 3-9
2015590-001
Controls, Indicators, and Connectors: Front Panel Displays
UA Display
The UA area is summarized by Figure 3-5 and Table 3-5.
Figure 3-5. UA Display
Table 3-5. UA Display
Name Description
A UA Value
Up to three digits indicate the uterine activity
value—mmHg for internal monitoring or relative
units for external monitoring.
B UA Mode Title
An abbreviation indicates the monitoring mode in
use:
TOCO, IUP, or INOP.
30
TOCO
A
B
