Revision B 120 Series Maternal/Fetal Monitor 7-7
2015590-001
Calibration: Display Check
Display Check
The 120 Series Display is manufactured by Planar Systems, Inc. All adjustments are
made at the Planar factory. There is no calibration or replacement procedure for
either the Display Driver Board or the Power Controller Unit. Contact your GE
Service Representative for information about repair/exchange of the entire display
assembly.
WARNING
HIGH VOLTAGE—The 120 Series Monitor display generates
potentially dangerous voltages capable of causing personal injury
(high voltage pulses up to 195 VAC). Do not touch the display
electronics during operation!
CAUTION
ELECTROSTATIC DISCHARGE—The 120 Series Monitor
display uses CMOS and MOS-FET components. These
components are electrostatic sensitive. Unpack, assemble, and
examine this assembly in a static-controlled area only. When
shipping, use packing materials designed for protection of
electrostatic-sensitive components.
