8-14 120 Series Maternal/Fetal Monitor Revision B
2015590-001
Self-Tests: Diagnostic Control Screen
Corolan Network Status
If Corolan Address Checking is disabled on the Install Options screen, this field will
normally display NO ADDRESS. If Corolan Address Checking is enabled on the
Install Options screen, the monitor periodically performs an address test on the
Corolan wallplate the monitor is attached to. If the wallplate address lines are intact,
this field will display an OK status. If the monitor detects a problem, the monitor
automatically goes offline from the Corolan network. Table 8-3 provides an
explanation of the more common status indications that can be listed in this field.
Table 8-2. Main Board SW1 Switch Settings
Switch # Description
On (0) Position Off (1) Position
State
Display
Notation
State
Display
Notation
8 MECG Option Disabled
Enabled MECG
7MSpO
2 Option Disabled Enabled MSPO2
6 NBP Option Disabled
Enabled NBP
5FSpO
2 Option Disabled Enabled FSPO2
4 Clock Speed 16 MHz 16 MHz 20 MHz
3 Unused — —
2
J102 Output
Levels
Corometrics CORO
Hewlett-
Packard
1 Factory Test Disabled Enabled TEST
Table 8-3. Corolan Network Status Messages
Message Meaning
OK
Monitor is successfully communicating with the Corolan master device (e.g.
QS Server).
JUST STARTED
Contact GE Service Representative.
ADDRESS NEVER CHECKED
FLOATING ADDRESS There is a faulty address line in the wallplate.
INVALID ADDRESS CHANGE
A wallplate has been changed from one address to another. This could be
the result of a partially disconnected cable.
ADDRESS KEEPS CHANGING
Contact GE Service Representative.
ADDRESS CHANGING
