6-36 120 Series Maternal/Fetal Monitor Revision B
2015590-001
Functional Checkout Procedure: Preventative Maintenance Inspection Report
Preventative Maintenance Inspection Report
Customer________________________Customer Number________________ Date ____________________
FE________________________ FE ID ___________________Call Number __________________________
Equipment Serial Number __________________________ Software Revision CPU _________ DSP: ________
Configuration
Model 126__________ Model 128 __________ Fetal Movement Detection (FMD) __________
Model 129 __________ Communication Option __________ FSp0
2 __________
Tools Required
Visual Inspection
Inspect the following for excess wear and/or signs of damage
NOTE: GE Medical Systems Information Technologies hereby gives its customers permission to reproduce pages 6-36
through 6-39 of this manual for the purpose of servicing the equipment.
• Digital Multimeter • Static-Free Work Surface
• Plastic Alignment Tool • Mild Soap/Water Solution
• Standard Hand Tools • Isopropyl Alcohol
• Leakage Current Tester (E278-06 or equivalent) • Baum Manometer (for Models 128/128F/129/129F only)
•
Leg plate (2608DAO-1) • FECG/MECG Adapter (1442AAO)
•
Model 325 Simulator with Cables • Baum Test Connector (for Models 128/128F/129/129F only)
•
ESD Mat and Wristband • 120 Series Operator’s Manual (2015589-001)
•
Assembly Leakage Cable
F AC Power Cord F MSpO2 Cable/Sensor (Models 128/128F/129/129F only)
F Ultrasound Transducer F Receptacles
F MECG Patient Cable (Model 129F only) F Interconnect Cables
F Leg Plate F Correct Fuses
F Tocotransducer F Chassis
F IUPC Transducer F 2116 Keyboard (if used)
F IUPC Intermediate Cable F Front Panel Switches
F Remote Marker F Internal Harnesses/Connectors
F NBP Hose/Cuff (Models 128/128F/129/129F
only)
F Power Supply Fan
To Next Page
