Controls, Indicators, and Connectors: Front Panel Displays
MHR/P Area
The MHR/P area is summarized by Figure 3-7 and Table 3-7.
Figure 3-7. MHR/P Display
Table 3-7. MHR/P Display
Name Description
A MHR/P Value
Up to three-digits indicate the MHR/P in beats per
minute.
B
MHR/P Alarm Setting
Indicator
This symbol provides information about the MHR/P
audio alarm and the MHR/P high/low alarm limit
settings.
îš„ : An alarm setting is turned off.
îš„ : All alarm settings are enabled.
C MHR/P Mode Title
The mode title
MECG indicates MECG is the MHR/
P source; the mode title
PULSE indicates MSpO2 or
NBP is used as the source. Select the mode title
softkey to access the MHR/P Setup screen.
D
Maternal Heartbeat
Indicator
Flashes with each detected valid heartbeat—for
MECG only.
89
MECG
C
D
B
A
