Revision B 120 Series Maternal/Fetal Monitor 11-3
2015590-001
Peripheral Devices: Standard Input/Output Connectors
J109, J110, and J111 Connectors (RS-232C)
Three RS-232C serial interface receptacles allow connecting the 120 Series Monitor
to the following devices:
îš„ Nellcor Puritan Bennett (NPB) N-200 Maternal Oxygen Saturation Monitor
(J109 and J111 only)
îš„ Nellcor Puritan Bennett N-400 Fetal Oxygen Saturation Monitor
*
îš„
DINAMAP Model 1846, 1846SX, 8100, 8100T NIBP Monitors
îš„ DINAMAP Model 1846SX/Oxytrak Critical Care Monitor
îš„ Quantitative Sentinel/Perinatal System (any RS-232C connector)
When shipped from the GE factory, all three ports are configured as follows:
îš„ communications mode = NELLCOR
îš„ baud rate (bps) = 2400
At the above settings, connectors J109 and J111 are ready for connection to an NPB
Model N-200. Connector J110 does not support a connection to NPB monitors;
therefore, this connector will have to be configured for the device to which it is
attached.
1. Select the
SERVICE softkey from the General Setup screen.
2. The Service Lock screen appears.
3. Enter the correct access code; the Install Options screen displays.
4. Select the
COMM softkey on the Install Options screen.
5. The Communications Setup screen appears.
6. Set the baud rate and mode for each port.
Baud Rate
This field selects the baud rate and must be compatible with the external device.
Use the Trim Knob control to cycle through the available settings: 600, 1200, 2400,
4800, 9600, and 19,200 bps. (Each port is factory set to 2400 bps.)
Mode
This field selects the mode for communication and must be compatible with the
external device. Use the Trim Knob control to cycle through the available settings:
NELLCOR, FACTORY, CRITIKON, 1371, and 1371/NOTES. (Each port is
factory set to the NELLCOR mode.)
NOTE: The FACTORY mode is reserved for factory testing only.
*
The NPB Model N-400 Fetal Pulse Oximetry Monitor is not available in all countries.
