Revision B 120 Series Maternal/Fetal Monitor 9-13
2015590-001
General Maintenance: Maternal Blood Pressure Tests
Unit to Primary Leakage
1. Set the fixture’s Leakage switch to Unit.
2. Turn ON the monitor using the monitor’s power switch.
3. Verify the following:
F < 300 µA (100, 120, 220, 230, or 240 VAC monitors)
4. Record the primary leakage for the following conditions:
Table 9-2. Unit to Primary Leakage Conditions
Neutral Ground Power (Polarity)
Closed Closed Normal
Closed Open Normal
Closed Open Reversed
Closed Closed Reversed
Open Closed Normal
Open Open Normal
Open Open ________ Reversed
Open Closed Reversed
