Controls, Indicators, and Connectors: Front Panel Displays
Table 3-4. Connectors vs. Display Modes
Active Connectors
FHR1 Area FHR2 Area
FECG
FECG INOP
FECG/US
FECG US
FECG/US2
FECG US2
US
US INOP
US/US2
US US2
US2
US2 INOP
—
INOP INOP
FECG/US/US2
a
a
If three FHR transducers are plugged in, the FECG signal overrides the US signal.
FECG US2
