Revision B 120 Series Maternal/Fetal Monitor 7-15
2015590-001
Calibration: Display Check
Figure 7-2. Partial Inside Front Panel, Shown with Front Bezel Removed
FSpO2
MATERNAL
SpO2
FECG/MECG
UA
US2
US
J6
J7
BP
Clip for FSpO2 cable ferrite
bead, if installed
Clip for FECG/MECG
ferrite beads
Ferrite bead is mou
clip attached to bac
display shield on fro
if FSpO
2 installed
Clip for FSpO2 ferrite bead (if
FSpO
2 installed)
Clip for MECG ferrite
bead (if MECG installed)
Clip for FECG
ferrite bead
FSpO2 ferrite bead mounts
to clip attached to back of
display shield on front bezel
(if FSpO
2 installed)
Clip for MSpO2 ferrite bead
(if MSpO
2 installed)
BP tube attachment on
rear side of connector
panel
