8-16 120 Series Maternal/Fetal Monitor Revision B
2015590-001
Self-Tests: Diagnostic Control Screen
AWAITING POLL
The Corolan master device (e.g. QS Server) re-started and sent an initial
handshaking message; however no further communication occurred.
MANAGER NOT ACTIVE
Contact GE Service Representative.MANAGER TOO SLOW
MANAGER RUNNING SLOW
AWAITING FIRST PACKET DATA
Fifteen seconds have elapsed since monitor was first turned on. (Data is
usually sent in 15-second packets.)
NO I FRAME FORMATTED YET Contact GE Service Representative.
TRANSMIT ON NEXT POLL
The monitor has received data and will respond on the next poll from the
master device (e.g. QS Server).
IN RE-TRANSMIT DELAY
Contact GE Service Representative.
TRANSMISSION RETRIED
DATA OVERFLOW
POLLS 15 SEC APART
POLLS 2 SEC APART
BACKLOG
Table 8-3. Corolan Network Status Messages
Message Meaning
